Production Introduction
|
|
Advantage
1.Whole machine is cast iron structure,the stability is excellent,not easy to be deformed.
2.Three axis adopted ball screw and linear orbit,stable working,high precision and long using life.
3.DSP control system with USB port,just need the handle to operate the machine,easy and convenient.
4.With T.slot working table,holding the materials with clamps,you can do variety of high precision works.
5.X,Y axis is dust proof,it makes sure the steady working performance of the machine for long term using.
Product Specification
Name/Mode | GD-6090 |
WorKing size | 600*900mm |
Feeding height | 150mm, (Customized) |
Travelling speed | 6000-10000mm/min |
Tool diameter | ￠3, ￠4, ￠6, ￠8, ￠12.7, etc |
Transmission mode | Xy precision helical gear transmission, Z imported brand screw drive |
Software working environment | WindowsXP/7 |
Spindle power | 1.5KW/2.2KW (Optional) |
Driver motor | servo motor |
Working voltage | 220v |
Engraving command | (G code) (nc), mmg, plt, eng, dxf |
Spindle rotating speed | 6000-24000rpm/min |
Control system | DSP |
Spindle speed | 0-24000rpm |
Company
| After-sale service 1. Training how to install the machine, training how to use the machine online. 2. Engineers available to clients' factory for training if necessary. 3. Guarantee for one year 4. 24-hour technical support by email or calling 5. User-friendly English manual for machine using and maintaining 6. Free technician training for customers. |
